Liquid Photopolymer Flexo Resin Plate Making Machine

This set Liquid Photopolymer Flexo Resin Plate Making Machine including one set liquid plate making exposure machine, liquid plate making washing machine, liquid plate making De-tacker& drying machine, liquid plate making vacuum glue machine, liquid plate making blender and liquid plate making flusher.

1. The exposure machine of the automatic liquid liquid version; 2. Tablet -type washing/baking all -in -one machine; 3. Tablet -type optical curing band water heating machine; 4. Vacuum suction machine; 5. Washing machine; 6. One composition of the stirring belt; 7. Two automatic heating boxes; 8. A set of automatic hand -to -vehicle systems. The exposure machine is controlled by PLC touch screen, the next exposure uses the imported LED lamp beads to dry the lamp, and the exposure of the imported LED lamp beads is used with high quality, high energy, energy saving, environmental protection, high efficiency, long life, safety, quality, quality The advantages of stable, uniform and stable light sources, and convenient operation can make high network lines, small text, small lines of liquid resin version. The version of the version is close to the solid version effect. The upper and lower glass uses the "AGC" 25mm glass imported from Japan; after special precipitation, it ensures its flatness and accuracy, and the flatness reaches ± ≤0.05mm. Adopt a computer touch screen control system.

The washing version is the transmission -type washing version. The bearing is not soaked in water. It is directed to change the bearings often, with water heating device, with a two -layer oven; Set a two -layer baking cabinet, and the temperature difference between the oven is ± ≤5 ° C.

Washing is a brush rotating version, with automatic constant temperature and filtering circular device. The pressure of the solid version and brush can be adjusted to avoid being adjusted when the local washing pressure is not uniform. Add automatic adhesive glue. Set a two -layer baking cabinet, and the temperature difference between the oven is ± ≤5 ° C.

The De-tacker&Dry  machine uses imported LED lamp beads to remove the adhesive tube, with water heating function;

All equipment uses a stainless steel body, and the hydrophilic area is made of 304#stainless steel plate. Comes with a semi -automatic hand cart, no need to charge another fee
