Description
1) Excellent dot and isolated line reproduction
2) Solid printing performance
3) High latitude of exposure and processing
4) Good ink transfer
5) High impression
Specification Parameters
| Type | AA394-1 |
| Thickness(mm) | 3.94mm |
| Rigidity(Shore A) | 43 |
| Recommend relief depth(mm) | 1.8-2.0 |
| Image reproduction | 3-95% |
| Maximum line line/inch | 100 |
| Minimum isolated line | 0.3mm(0.0118inch) |
| Minimum isolated dot | 0.50mm(0.0197inch) |
| Suitable Ink | Suitable for water and alcoholbased ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25% |
| Mainly applicable field | Corrugated board, Thick board, Paper |
Size mm(inch)
| 457×762 (18×30) | √ | 1067×1524 (42×60) | √ |
| 762×1016 (30×40) | √ | 1067×2032 (42×80) | √ |
| 762x1067 (30x42) | √ | 1270×2532 (50*80) | √ |
| 900×1200 (35.4×47.2) | √ |
